è possibile Importare
ed Esportare file dai seguenti Software:
Supported Import File
Formats
|
All previous Protel/Altium
Schematic files/libraries
|
All previous Protel/Altium
PCB files/libraries
|
|
|
Protel 99SE Design Database (*.ddb)
|
P-CAD V16 or V17
Binary Schematic design files (*.sch)
|
|
|
P-CAD V15, V16, or
V17 Binary PCB design files (*.pcb)
|
P-CAD V15, V16, or
V17 ASCII PCB design files (*.pcb) |
|
|
P-CAD V16 or V17
Binary Library files (*.lib)
|
P-CAD V16 or V17
ASCII Library files (*.lia) |
|
|
P-CAD PDIF file (*.pdf)
|
Tango PCB ASCII files (*.pcb) |
|
|
CircuitMaker
Schematics (*.ckt)
|
CircuitMaker User
Libraries (*.lib) |
|
|
CircuitMaker Device
Libraries (*.lib)
|
Eagle Schematic (*.sch) |
|
|
Eagle PCB (*.pcb)
|
Eagle Library (*.lbr) |
|
|
OrCAD Capture
Designs (*.dsn)
|
OrCAD Capture
Libraries (*.olb) |
|
|
OrCAD Layout PCB
documents (*.max)
|
OrCAD PCB Libraries
(*.llb) |
|
|
OrCAD CIS
Configuration file (*.dbc)
|
OrCAD SDT (*.sch) |
|
|
PADS Layout ASCII
Design files (*.asc)
|
PADS Layout ASCII
Decal Libraries (*.d) |
|
|
PADS Logic ASCII
Design files (*.txt)
|
PADS Logic ASCII
CAE Decal Libraries (*.c) |
|
|
PADS Logic ASCII
Part Type Libraries (*.p)
|
DxDesigner Designs
and Libraries |
|
|
Expedition files
(*.pcb, *.lib)
|
CADSTAR Schematic
Archive (*.csa) |
|
|
CADSTAR PCB Archive
(*.cpa)
|
CADSTAR Part
Library (*.lib) |
|
|
Allegro binary PCB (*.brd)
|
Allegro ASCII PCB (*.alg) |
|
|
Specctra Design file (*.dsn)
|
AutoCAD DWG/DXF (*.dwg,
*.dxf) |
|
|
File Types |
|
Description |
|
|
|
|
|
|
|
Protel 99SE DDB
Files
|
|
99SE DDB (*.ddb)
|
|
|
Cadence® Allegro®
Design Files
|
|
Allegro binary PCB
(*.brd), Allegro ASCII PCB (*.alg)
|
|
|
Zuken CADSTAR®
Designs and Libraries
|
|
CADSTAR Schematic
Archive (*.csa), CADSTAR PCB Archive (*.cpa), CADSTAR Part
Library (*.lib)
|
|
|
CircuitMaker 2000
Schematics and Libraries
|
|
CircuitMaker
Schematics (*.ckt), CircuitMaker User Libraries (*.lib),
CircuitMaker Device Libraries (*.lib)
|
|
|
Mentor Graphics®
DxDesigner® Designs and Libraries
|
|
DxDesigner Designs,
DxDesigner Libraries
|
|
|
Mentor Graphics®
Expedition® Designs and Libraries
|
|
Mentor Expedition
files (*.pcb, *.lib).
|
|
|
Cadence® OrCAD®
Designs and Libraries
|
|
OrCAD Capture
Designs (*.dsn), OrCAD Layout PCB documents (*.max), OrCAD
Capture Libraries (*.olb), and OrCAD PCB Libraries (*.llb)
|
|
|
Cadence® OrCAD® CIS
Configuration Files and Libraries
|
|
OrCAD CIS
Configuration file (*.dbc) and OrCAD Library files (*.llb, *.olb)
|
|
|
Mentor Graphics®
PADS® Layout and PADS® Logic Designs and Libraries
|
|
PADS Layout ASCII
Design files (*.asc), PADS Layout ASCII Decal Libraries (*.d),
PADS Logic ASCII Design files (*.txt), PADS Logic ASCII CAE
Decal Libraries (*.c), PADS Logic ASCII Part Type Libraries
(*.p)
|
|
|
Cadence® OrCAD® and
Mentor Graphics® PADS® Designs and Libraries
|
|
OrCAD Capture files
(*.dsn), OrCAD Schematic Library files (*.olb), PADS Logic ASCII
Design files (*.txt), PADS Layout ASCII Decal Libraries (*.d),
PADS Logic ASCII CAE Decal Libraries (*.c), PADS Logic ASCII
Part Type Libraries (*.p)
|
|
|
P-CAD Designs and
Libraries
|
|
P-CAD V16 or V17
Binary Schematic design files (*.sch), P-CAD V16 or V17 ASCII
Schematic design files (*.sch), P-CAD V15, V16, or V17
Binary PCB design files (*.pcb), P-CAD V15, V16, or V17 ASCII
PCB design files (*.pcb), P-CAD V16 or V17 Binary Library files
(*.lib), P-CAD V16 or V17 ASCII Library files (*.lia)
|
|
|
CadSoft® EAGLE™
schematic, PCB and Libraries
|
|
EAGLE design files
saved with EAGLE version 6.4.0 (or later). These files are
XML-format – EAGLE binary-format design files cannot be imported
using the EAGLE Importer, they must first be saved in XML-format
in EAGLE. |
|
Supported Export File
Formats
Schematic Editor
|
Altium Schematic
Binary (*.SchDoc)
|
Altium Schematic
ASCII (*.SchDoc)
|
|
|
Altium Schematic
binary 4.0 (*.sch)
|
Altium Schematic
ASCII (*.SchDoc)
|
|
|
OrCAD SDT Schematic
(*.sch)
|
OrCAD v7 Capture
Design (*.dsn)
|
|
|
Altium Schematic
Template (*.SchDot)
|
AutoCAD DWG/DXF (*.dwg,
*.dxf)
|
|
PCB Editor
|
Altium PCB Binary
(*.PcbDoc)
|
Altium PCB binary
V3.0, V4.0 (*.PCB)
|
|
|
Altium PCB binary
V5.0 (*.PcbDoc)
|
Altium PCB ASCII
(*.PcbDoc)
|
|
|
Protel Netlist
(*.net)
|
AutoCAD DWG/DXF (*.dwg,
*.dxf)
|
|
|
HyperLynx (*.hyp)
|
P-CAD ASCII (*.pcb)
|
|
|
Protel PCB 2.8
ASCII (*.pcb)
|
Protel Netlist
(*.net)
|
|
|
Specctra Design
File (*.dsn)
|
SDRC-IDF Brd Files
(*.brd)
|
|
|
STEP (*.step, *.stp)
|
SiSoft Files (*.csv)
|
|
|
Ansoft Neutral File
(*.anf)
|
|
|
Schematic Library Editor
|
Altium Schematic
Binary Library (*.SchLib)
|
Altium V4.0
Schematic Binary Library (*.lib)
|
|
|
OrCAD Capture
Schematic Library (*.olb)
|
P-CAD V16 Schematic
Library (*.lia)
|
|
PCB Library Editor
|
Altium PCB Library
(*.PcbLib)
|
Altium V3.0, V4.0
Library (*.lib)
|
|
|
Altium V5.0 Library
(*.PcbLib)
|
P-CAD V16 PCB
Library (*.lia)
|
|
